Inspection and Installation

• When using one crossover cable to connect PC directly, the gateway address of

the instrument should be consistent with that of the PC, and the IP address

should be at the same network segment with the PC’s IP address.

• When the instrument and computer are connected to the router, an independent

IP address must be assigned for the instrument.

View LAN Interface Information

The operation steps to view the LAN interface information in the System Menu

are as follows.

1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-

ter the system menu.

2. Rotate the knob or press the Up/Down key to select I/O and press [Enter].

3. Press the Left/Right key to select LAN and press [Enter].

4. Press the Left/Right key to select Info and press [Enter].

5. Press the Up/Down key or rotate the knob to view the LAN parameters. See

the information in 1.8 System Menu Function for details.

Configure LAN Interface Information

The configurable parameters of the IT6000D series power supply are described

as follows.

IP-Conf

• IP: This value is the Internet Protocol (IP) address of the instrument. An IP

address is required for all IP and TCP/IP communications with the instru-

ment. An IP Address consists of 4 decimal numbers separated by periods.

Each decimal number ranges from 0 through 255 with no leading zeros (for

example, 169.254.2.20).

• Mask: This value is used to enable the instrument to determine if a client IP

address is on the same local subnet. The same numbering notation applies

as for the IP Address. When a client IP address is on a different subnet, all

packets must be sent to the Default Gateway.

• Gateway: This value is the IP Address of the default gateway that allows the

instrument to communicate with systems that are not on the local subnet, as

determined by the subnet mask setting. The same numbering notation ap-

plies as for the IP Address. A value of 0.0.0.0 indicates that no default gate-

way is defined.

• DNS1: This field enters the primary address of the server. Contact your LAN

administrator for server details. The same numbering notation applies as for

the IP Address. A value of 0.0.0.0 indicates that no default server is defined.
