Power Supply Function
Repeat Repeat times, the setting range is 1~65535.
End State
Indicates the end state. Last (voltage or current main-
tained at the last point after completion) or Normal
(return to the mode before CDWELL execution after
completion).
Total Point
The total number of waveform points.
Keep Time
Indicates the pulse width of each point. Range:
0~3600. Unit: seconds.
Value
Voltage or current value at each point.
– List: User-defined waveform
The fields included in the .csv template file are explained as follows:
Model
Device model, keep the default settings without
modification.
Firmware
Version
Firmware version number, keep the default settings
without modification.
Serial Number
Device serial number, keep the default settings with-
out modification.
File Type
File type, keep the default settings without
modification.
Waveform Type
Waveform type, keep the default settings without
modification.
Vaule Unit The CV priority is set to V, and the CC priority is set to
A.
Slope Unit Slope unit, fixed to S.
Time Unit Time unit, fixed to S.
Mode Indicates the power supply working mode. The CV
priority is set to CV, and the CC priority is set to CC.
Step Count The total number of steps, up to 10 million points can
be edited.
Repeat Repeat times, the setting range is 1~65535.
End State
Indicates the end state. Last (the voltage or current
maintained at the last step after the end) or Normal
Copyright © Itech Electronic Co., Ltd.
73
