Power Supply Function
4.6.1.1 ARB Function
This series of instruments comes standard with ARB (arbitrary waveform) func-
tion, which allows the output of user-defined arbitrary complex voltage or current
waveforms. It can be operated in the following ways:
• Import via U disk
The instrument supports importing the edited .csv format file (the template
can be obtained by contacting ITECH personnel) through the USB interface
on the front panel, and generating voltage or current values after parsing,
and then outputting complex voltage or current waveforms according to the
time width specified by the user. The user can edit a .csv file containing up
to 10 million voltage or current points and import it into the instrument for
running to realize arbitrary waveform output or working condition simulation.
The instrument has the ability to quickly parse data. A .csv file of dozens of
megabytes can be imported and parsed within 5S, making testing more con-
venient and efficient.
This instrument supports importing the .csv files corresponding to the follow-
ing waveforms:
– CDWELL: Constant dwell arbitrary waveform
The fields included in the .csv template file are explained as follows:
Model
Device model, keep the default settings without
modification.
Firmware
Version
Firmware version number, keep the default settings
without modification.
Serial Number
Device serial number, keep the default settings with-
out modification.
File Type
File type, keep the default settings without
modification.
Waveform Type
Waveform type, keep the default settings without
modification.
Value Unit
The CV priority is set to V, and the CC priority is set to
A.
Offset Unit
Offset value unit, CV priority is set to V, CC priority is
set to A.
Time Unit
Time unit, fixed to S.
Mode
Indicates the power supply working mode. The CV
priority is set to CV, and the CC priority is set to CC.
Copyright © Itech Electronic Co., Ltd.
72
