Quick Reference
Prescaler Prescale
BS1 Value PTS
BS2 Value PBS
Display RS232
or GPIB accord-
ing to optional in-
terface. In
addition, RS232
interface and the
analog interface
share an inter-
face position.
RS232 Select RS-232 communication interface.
Baudrate
Baud rate: 4800/9600/19200/38400/57600/
115200
Databit Data bit: 5/6/7/8
Parity
Parity bit: N (No parity) / E (Even parity) / O
(Odd parity)
Stopbit Stop bit: 1/2
GPIB Select GPIB communication interface.
Address
Set the communication address (1 to 30).
Parallel
Set the instruments to parallel operation mode.
Single
Set the instrument to single mode, i.e., disable the parallel
operation mode.
Master Set the instrument to master mode.
Total Unit
Number of parallel instruments.
Slave Set the instrument to slave mode.
Digital Port
Set Digital I/O
By default, the menu item displays 7 options. You can set parameters
for each option respectively. After setting, the corresponding change to
each option becomes valid immediately. When re-entering DigPort,
the interface can display the changed option. For detailed introduction
of menus and functions, see 5.11 Digital I/O Function (Digital Port).
IO-1. Ps-Clear, Not-
Invert
Function setting of pin 1
IO-2. Ps, Not-Invert
Function setting of pin 2
IO-3. Off-Status, Not-
Invert
Function setting of pin 3
IO-4. Ext-Trig, Not-
Invert
Function setting of pin 4
IO-5. INH-Living, Not-
Invert
Function setting of pin 5
IO-6. Sync-On, Not-
Invert
Function setting of pin 6
IO-7. Sync-Off, Not-
Invert
Function setting of pin 7
Ext-Program
External Analog Function. This function is optional. The menu can only
display when corresponding board card is inserted. For details, see
5.12 Analogue Function (Ext-Program) (Optional).
System Reset Select whether to restore the factory default settings or not.
