Power Supply Function
the outer loop interfaces TX and RX of the fiber to
realize List synchronization triggering between
multiple units.
None Turn off (default)
Tout Turn on
Save to
group
Save the edited List program.
Edit List Program
The following takes CC priority mode as an example to introduce the operation
of editing two test steps.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
ter the function menu.
2. Select 1. LIST: Off and press [Enter].
3. Press the Left/Right key to select Edit and press [Enter] to enter the editing
interface.
4. Select CC and press [Enter] to confirm.
5. Set the total number of steps in the List program and press [Enter] to
confirm.
6. Set the current, slope and time width of step 1 in turn, and press [Enter] to
confirm.
7. Set the parameters of step 2 in the same method.
8. Set the number of list repetitions Repeat, and press [Enter] to confirm.
9. Set the End State as Normal, and press [Enter] to confirm.
10.Depending on the test requirement, choose whether to turn on the function
switch that triggers synchronization.
11. Set the currently edited List program name.
If you choose not to save, press [Esc] to exit the editing interface.
Import List Program
If you need to run the List program on the external USB flash drive, you need to
import the List program from the USB flash drive into the instrument.
Copyright © Itech Electronic Co., Ltd.
59
