ITech IT8731 User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 74
Input impedance
≒1MΩ
dimension
82*183*573
weight
5KG
*1 Dynamically allocate power. The maximum power of single channel is 250W. The total power
of both channels is less than or equal to 300W. The average power of each channel is 150W.
*2 The voltage/current input is no less than 10% FS (FS= Full Scale)
*3 The scope of read-back resistance is ( 1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08) )
*4 Dynamically allocate power. The maximum power of single channel is 250W. The total power
of both channels is less than or equal to 300W.
*5 The voltage/current input is no less than 10% FS
*6 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current
*7 Minimum rise time: 10%-90% current rise time
Model
IT8732BP
Rated value
( 0～40 ℃)
Input voltage
0~500V
Input current
0~20A
Input power
300W
Min operation
voltage
0.72V/3A
4.8V/20A
CV mode
Range
0~18V
0~500V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.025%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~3A
0~20A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CR mode
*1
Range
0.25Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
300W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic mode
CC mode
T1＆T2
20uS~3600S/Res:1uS
Accuracy
5uS±100ppm
Rising/falling slope
*4
0.0001~0.1A/uS
0.001~0.8A/uS
Min Rising time
*5
≒20uS
≒20uS
Measuring range
Readback voltage
Range
0~18V
0~500V
Resolution
1 mV
10 mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback current
Range
0~3A
0~20A
Resolution
0. 01mA
0.1mA
Accuracy
±(0.05%+0.05%FS)
Readback power
Range
300W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
≒310W
OCP
≒3.3A
≒22A
OVP
≒530V
