Panel function introduction

3.1.2 Menu list

Different modules of IT8700 series electronic loads have different setting and

configuration menu according to different working modes.

Press key to enter menu setting, view the menu in VFD and use

and to scroll through the completely menu list as following. Press

key to enter the selected menu function, use and to

scroll through the VFD screen, press key to enter the under submenu,

press back to the previous menu selection page.

Setting menu

Press key to enter menu setting.

⚫ Setup menu list of

IT8732B/IT8733/IT8733B/IT8731/IT8732/IT8722/IT8723/IT8722B:

Setup

MODE

Select working mode

Const Current

Load works in CC mode

Const Voltage

Load works in CV mode

Const Resistance

Load works in CR mode

Const Power

Load works in CW mode

CC/CV RANGE

Switch the range

High Range

Low Range

I / V / R /W SET

Set the working current/voltage/resistance value

Vmax/Amax

Setup the maximum voltage value/maximum current value

Vmin/Amin

Setup the minimum voltage value/minimum current value

Vd=0.000V

Set the break-over voltage value( Only for CR-LED mode)

∫=2.500A/uS

Set the up slope (only CC mode available)

∫=2.500A/uS

Set the down slope(only CC mode available)

TRAN A=0.00A

Setup level A value

Ta=0.0005S

Setup level A width

TRAN B=0.00A

Setup level B value

Tb=0.0005S

Setup level B width

T MODE

Setup the transient mode

Continuous

Continuous mode

Pulse

Pulse mode

Toggle

Toggle mode
