RotatetheCameraBody

Ideally,formostintersectionapplications,vehiclesshouldflowfromthetopofthescr eentothebottom
ofthescreen.Bylooseningthetwohoseclampsetscrews,thecamerabodycanrotatetobettersquare
uptheFOVimage.
Thecarbumpersshouldalsoendupbeingparallelwith
thebottomofthescreen.
 
Figure3.1.1(k)Figure3.1.1(l)
ThecamerabodycouldberotatedTheabovepictureshowsanacceptable
tohelpsquareupthestopbararea  FOVandstopbarareaalignment.

OtherImportantFieldofViewConsiderations

1)MakesurethatthereisnohorizonintheFOV.ThiscanresultinseriousoperationalproblemsforEast
or Westapproaches.Why? Becauseofthesun!Duringsunrise or sunset the sun can completely blind
thecamera.ProperFOV,visoradjustment,andcameratiltcanpreventthispotential
problem.

PoorSetup‐HorizonIsIncludedAsPartofTheField ofView(FOV)


Figure3.1.1(m)
2)Makesure the stopbararea  is locatedtowardthebottomof the FOV. This willalsoleaveroom for
advancezonedetection.Thefollowingexamplephotoshowsthestopbararealocatedinthemid dle of
theFOV,whichisnottheideallocation.

PoorSetup‐Stop
barAreaIsInTheMiddleofTheFieldofView(FOV)
Figure3.1.1(n)
