3.3.4 ICC-2W Module Installation
The ICC‐2W module is designed to be installed in a standard NEMA TS‐1 or TS‐2 detector rack or in a
standard332cabinettypedetectorinputfile.Totherack,theICC‐2Wmodulelookslikeafourchannel
detector loop amplifier. Though the ICC‐2W
 module foot print takes  up two rack spaces like a four
channelloopamplifier,theoutputboardedgeconnectoronlyplugsintooneofthedetectorrackslots–
theslotontheright.Thisslotis wherethefourlogiclevelcontactclosureoutputswillbeplacedandwill
callthephaseor phases associatedwith that detectorslot.Where youplugtheICC‐2W module inthe 
detector rack will determine what phases it will call when the detection zone associated with that
channelisactivated.
TheICC‐2Wmoduleoperateson120‐240VAC,realize thatthemodule
alsorequires12or24VDCfrom
the detectorrackoroutput  file to operate if you are bringing AC into the front ofthemodule.Having
correctly terminated the power and communication wires from the Base Station as described in the
previous section, plug the ICC‐2W module into the
detector rack or you can install the module into a
VantageVRack1forstandaloneoperation.MakesuretheICC‐2WmodulehasACpower(andDCpower
ifACpowerisbeingbroughtinthroughthefront).Makesurethecorrectpolarityhasbeenobservedon
DC and communications wire pairs.
 The ICC‐2W module should power up and the green ON LINE LED
should come on solid. If the green ON LINE LED fails to illuminate check the AC power and power
connections.IfthegreenONLINE LEDstillfailstoilluminatecallIterisProductSupport.
ExternalSurgeProtection

Anexternalsurgeprotectiondeviceisavailableandisrecommendedforallinstallations.Seesection9.3 
formoredetails.









