9.4 VersiCam Wireless Technical Information
 Camera ICC‐2WModule ICC‐2WShelfMount BaseStation
Features Colorimager 170inputfile
compatible
Compactenclosure 
 768x494effective
pixels
TS1compatible 
 470TVlines TS2compatible 
 Automaticwhite
balance

 >50dBS/Nratio 
 0.1luxcapable
Lens Focallengthandfocus
adjustablefor
horizontalFOVranging
from5.4
o
teleto85
o

wide

Connections Terminal
–
4way Terminal
–
6wayfor
BaseStation
Terminal
–
6wayfor
BaseStation
TerminalStrip
–
4way
 2xDCPower 2xDCPower 2xDCPower 2xDCPower
 2xDifferentialControl 2xDifferentialControl 2xDifferentialControl 2xDifferentialControl
  2xUnused(for
productionuseonly)
2xUnused(for
productionuseonly)

  Terminal
–
3wayfor
PowerInput
Terminal
–
3wayfor
PowerInput

  RS‐232port RS‐232port 
Mechanical
Dimensions
13.5”(L)x4”(D) 7”(L)x4.5”(H)x
2.3”(W)
8.3”(L)x5”(H)x
2.8”(W)

 34.3cmx10.2cm 17.78cmx11.43cmx
5.85cm
17.78cmx11.43cmx
5.85cm

 Withoutbracket
Weight  1.05lbs/0.48kgs 2.4lbs/1.09kgs 
Environmental 
Temperature ‐31
o
Fto+140
o
F ‐35
o
Fto+165
o
F ‐35
o
Fto+165
o
F ‐31
o
Fto+140
o
F
 ‐35
o
Cto+60
o
C‐37
o
Cto+74
o
C ‐37
o
Cto+74
o
C ‐35
o
Cto+60
o
C
Humidity 0‐100%relative 0‐ 95%relative 0‐ 95%relative 0‐100%relative
 Non‐condensing Non‐condensing Non‐condensing Non‐condensing
Vibration 0.5G,3axes,5‐30Hz 0.5G,3axes,5‐30Hz 0.5G,3axes,5‐30Hz 0.5G,3axes,5‐30Hz
Shock 10G,3axes 10G,3axes 10G,3axes 10G,3axes
PowerInput 15‐24VDC,output23W
typical
100‐240VAC50/60Hz
0.7A
100‐240VAC50/60Hz
0.7A
15‐24VDC,output1W
typical
Output RS‐485Serial 15VDC 15VDC RS‐485Serial
 2.4GHzradio 27Wtypical 27Wtypical 2.4GHzradio

