3.3.3 ICC-2W Module AC Power Requirements
TheICC‐2WModulerequiresACpower(100‐240vac50/60Hz)whichcanbesuppliedbytheconnector
onthefrontpanelorcanbesuppliedfromthebackplaneontherack.Powertothebackplaneis
suppliedonpinsL,MandN,seeFigure3.3.3(a).
BackPlanePins
 120VAC
L ChassisGround
M AC–Neutral
N AC+Hot
Figure3.3.3(a)
Note:thebackplaneconnectionisonlysuitablefor120vmaximum.
Ifyouhavea 240vsourceusethepowerconnectoronthefrontpanel.IfACpowerisavailablefromthe
rackthefrontpanelconnectorisdisabled.IftherackdoesnotprovideACpowerusethepre
‐wiredAC
powercord,seeFigure3.3.3(b).
Figure3.3.3(b)
Plugthegreen3pinconnectorintothesocketonthefrontofthemodule,seeFigure3.3.3(c).Plugthe
cordintoasuitable120vor240vsource.
Figure3.3.3(c)
