Iteris VersiCam - 5 Versicam Options; Output Configuration

49

5 VersiCam Options
TheVersiCamcan beinstalledinmost standardNEMAdetectorracks  and332cabinet typeinputfiles.
There is also an optional stand alone VCRack (VersiCam Rack), see Figure 4(a), that can be used for
applicationswhereadetectorrackorinputfilearenotavailableorarenotpractical. 
Figure4(a)
5.1 Output Configuration
ThebackplaneoftherackhasaDB9connectortointerfacewiththeinputfile.UsethesuppliedCCable
toconnectfromtheracktotheinputfile.SeeFigure5.1(a)forpinconfiguration.
Pin
Number
PinFunction CameraAssignment
1 Output1 Camera1Output1
2 Output2 Camera1Output2
3 Output3 Camera2Output1
4 Output4 Camera2Output2
5 NotUsed NotUsed
6 NotUsed NotUsed
7 NotUsed NotUsed
8 NotUsed NotUsed
9 LogicGround N/A
Figure5.1(a)

