Materials Not Provided by Itron
The following Coaxial Specifications table lists several options for coaxial cable that can
be used with the remote mount high gain 900 MHz antenna. When a high gain antenna is
installed on a standard collector or repeater, follow the FCC set limits for the maximum
transmit power of the collector or repeater. To meet FCC limits, standard collectors or
repeaters must have a minimum of 2.2 dB worth of loss (but not more than 3.5 dB)
between the collector or repeater and the antenna.
Allow 0.1 dB loss for each connector. If required, you may use a 1 dB attenuator (similar
to the Pasternack PE7002-1) to attain the desired power at the antenna for short coaxial
cable runs.
Remote Mount High Gain (8.15 dBi) 900 MHz Antenna on a Tower
CCU
The following Coax Specification table lists several options for coaxial cable that can be
used with the remote mount high gain 900 MHz antenna. When a high gain antenna is
installed on a tower collector, follow the FCC set limits for the maximum transmit power
of the collector. To meet these limits, tower collectors with FCC ID number
EO9CCU100T must have a minimum of 2.2 dB worth of loss (but not more than 3.5 dB)
between the tower cabinet and the antenna. Install all other tower collectors with
minimum cable loss.
Allow 0.1 dB loss for each connector. If required, you may use a 1 dB attenuator (similar
to the Pasternack PE7002-1) to attain the desired power at the antenna.
Coax Specification 0-100' ft. 0-120 ft. 121-200 ft. (high-
201-250 ft. (high-
Standard black jacket cable LMR-400-DB AVA5-50 AVA6-50 AVA7-50
Optional fire retardant cable LMR-400-FR AVA5RK-50 AVA6RK-50 AVA7RK-50
Cable diameter (nominal) 0.405 in. 7/8 in. 1-1/4 in. 1-5/8 in.
Cable weight (lb./ft.) 0.068 0.33 0.46 0.70
Minimum bend radius 1 in. 10 in. 8 in. 15 in.
Cable attenuation @ 915
MHz
2.2 dB/57ft. ~ 1.2 dB/100 ft. ~ 0.84 dB/100 ft. ~0.70 dB/100 ft.
External GPS and WAN Antennas
The primary requirement for any coaxial cable used with the external GPS or WAN
antenna is to have less than 5 dB of attenuation at 1.5 to 1.8 GHz for the entire length of
cable, including connector losses.
You may use any type of 50 ohm coaxial cable as long as the total loss, including
connectors, is less than 5 dB at 1.5 to 1.8 GHz.
Itron recommends using regular 1/2" coax or Times Microwave LMR-400.
