Installing 40W and 50W ERT Modules PUB-0126-001 4/04
01551
Place the ERT module mounting
bracket on the work surface with
its inside up.
6-13
Place the ERT module on the
mounting bracket as shown, with
the cable routed through the exit
notch.
6-14
01552F
01014G
The ERT module and mounting
bracket should now look like this.
6-15
