Installing 40W and 50W ERT Modules
Get four Torx-head ERT module
mounting screws from the bulk
supply. The screws are shown
approximately actual size.
Install the Torx-head ERT module
mounting screws where shown.
Hand tighten every screw.
00983
01016
6-17
6-18
01015
Make sure the register cable is still in
the mounting bracket cable exit notch.
6-16
6-8
