SL7000 User Guide
voltage swell (phase 2)
Qualimetry
Quartet 4 : Bit 2
current reversal (phase 2)
Diagnostic & Tamper
Quartet 4 : Bit 3
voltage cut (phase 3)
Qualimetry
Quartet 5 : Bit 0
voltage sag (phase 3)
Qualimetry
Quartet 5 : Bit 1
voltage swell (phase 3)
Qualimetry
Quartet 5 : Bit 2
current reversal (phase 3)
Diagnostic & Tamper
Quartet 5 : Bit 3
No internal consumption
Diagnostic & Tamper
Quartet 6 : Bit 0
No external consumption
Diagnostic & Tamper
Quartet 6 : Bit 1
Zero sequence U
Diagnostic & Tamper
Quartet 6 : Bit 2
Zero sequence I
Diagnostic & Tamper
Quartet 6 : Bit 3
External alarm
Control input
Quartet 7 : Bit 0
Configuration incoherence
All functions
Quartet 7 : Bit 1
Non volatile memory
Memory manager
Quartet 7 : Bit 2
Excess demand
Demand Registering
Quartet 7 : Bit 3
No voltage (SL764)
Diagnostic & Tamper
Quartet 8 : Bit 0
Loss of voltage (SL764)
Diagnostic & Tamper
Quartet 8 : Bit 1
Current diversion (SL761) (FW > v8.00)
Loss of phase (SL764)
Diagnostic & Tamper
Quartet 8 : Bit 2
cover opening
Diagnostic & Tamper
Quartet 8 : Bit 3
Terminal cover openning (SL761)
Current loss (SL764)
Diagnostic & Tamper
Quartet 9 : Bit 0
Magnet sensor (SL761)
Power Off (SL764)
Diagnostic & Tamper
Quartet 9 : Bit 1
current reversal aggregate (SL761)
Power flow reverse (SL764)
Diagnostic & Tamper
Quartet 9 : Bit 2
Zero sequence I trapped (SL761)
Voltage reverse phase sequence (SL764)
Diagnostic & Tamper
Quartet 9 : Bit 3
On the second line (fatal error)
Internal RAM error.
Diagnostic & Tamper
Quartet 1 : Bit 0
External RAM error.
Diagnostic & Tamper
Quartet 1 : Bit 1
Internal program memory error.
Diagnostic & Tamper
Quartet 1 : Bit 2
External program memory error.
Diagnostic & Tamper
Quartet 1 : Bit 3
Non volatile memory fatal alarm
Diagnostic & Tamper
Quartet 2 : Bit 0
Several external clock incoherence
RTC
Quartet 2 : Bit 1
