4.1. Meter overview
The SL7000 is a static, polyphase, four-quadrant, multi-rate
meter. It is intended for large industrial to substation applications.
Depending on the factory configuration, the meter provides the following minimum features and functions:
Multi-energy registering
Active, Reactive and Apparent energy (import and export)
Units - Watt (W), Kilowatt (kW) and Megawatt (MW)
Maximum 32 individual energy rate registers for 10 energy channels
(incremental or cumulative)
Up to 8 energy rates per channel
Multi-rate billing and switching
Billing for both energy and demand
Energy rate switching performed by internal clock/calendar
 Up to 12 seasons
 Up to 24 day profiles
 Up to 16 switching times per day profile
 Up to 100 special days (repetitive or non-repetitive)
Demand registering
Maximum 24 individual demand rate registers for 10 demand channels
Up to 8 energy rates per channel
Load profiling
2 independent sets of 8 recording channels giving up to 16 load profile channels
Incremental data
Communication
RS232/RS485 configurable + RS232 or RS485
DLMS-Cosem compliant
PSTN, LAN (TCP/IP), GSM and GPRS media supported
Remote Firmware upgrade possibility
Network quality monitoring
Voltage cuts, sags and swells
Total Harmonic Distortion (THD)
Waveform capture (per phase Urms and Irms)
