10.3. MID display list
The MID display list will typically contain the following entries. However, further parameters may be included
depending on meter configuration, firmware revision and resource level.
Data
Zone Code
Zone Data
Zone Unit
Active TER import phase 1
‘IMP PH1’
‘00000000’
‘kWh’ or ‘MWh’,
according active
TER group
configuration
Active TER import phase 2
‘IMP PH2’
‘00000000’
Active TER import phase 3
‘IMP PH3’
‘00000000’
Active TER import aggregate
‘IMP AGG’
‘00000000’
Active TER export phase 1
‘EXP PH1’
‘00000000’
Active TER export phase 2
‘EXP PH2’
‘00000000’
Active TER export phase 3
‘EXP PH3’
‘00000000’
Active TER export aggregate
‘EXP AGG’
‘00000000’
MIDComplianceParameters
‘MID’ or
‘NOT MID’
SAP
'MEtEr'
'SLB761'
Metrology firmware revision
‘7 01C’
‘MTR REV’
Application firmware revision
’7 11A’
‘APP REV’
Loader firmware revision
V01 00I
‘LD REV’
Metrology checksum
‘FFFFFFFF’
‘MTR CHECK’
Application checksum
‘FFFFFFFF’
‘APP CHECK’
Loader checksum
‘FFFFFFFF’
‘LD CHECK’
Current connection parameters
‘connECt’
‘DIRECT’ or
‘TRANSF’
Energy active class
‘CLASS 02’ or
‘CLASS 05’ or
‘CLASS 1’ or ‘CLASS
A’ or ‘CLASS B’ or
‘CLASS C’
Current rating Iref
'I rEF'
‘1.0’
‘A’
Current rating Imax
'I MAX'
‘5.0’
‘A’
Connection type
‘USE’ or ‘VDE’
Port communication 1
‘Port 1’
‘NO’ or
‘RS 232’ or
‘RS 485’ or
‘TCP IP’
Port communication 2
‘Port 2’
‘NO’ or
‘RS 232’ or
‘RS 485’ or
‘TCP IP’
Voltage range
’57 7-100’ or
‘ 127-220’ or
‘ 230-400’ or
‘VOLTAGE’
‘V’
