9.4. Fixings
The meter is provided with two upper fixing points (1) and (2), select the appropriate one to use, as required. A
hanging bracket is also provided with the meter.
Two further lower fixing points are located within the terminal area; these can be accessed only by removing the
terminal cover.
Item
Dimension
Description
A
230
Upper fixing point (1) to lower fixing points (centre to centre)
