Item Quantity Part name Pump Material (3196,
HT 3196, CV 3196,
3796)
Pump Material (NM
3196)
Pump Material
(3198)
All Titanium Vinylester D.I./Teflon
241 1 Frame Foot
1001
248 1 Oil Thrower 2210
250 1 Gland—Mechanical Seal Material varies
253B 1 Bearing Clamp Ring 2210
319 1 Sight Glass Glass/steel
332A 1 Outboard Labyrinth Seal w/O-rings Brass ASTM B505-96
333A 1 Inboard Labyrinth Seal w/O-rings Brass ASTM B505-96
351 1 Casing Gasket Aramid fiber w/EPDM
353 4 Gland Stud 2156 2229 2229
355 4 Gland Stud Nut 2156 2229 2229
358 1 Plug—Casing Drain 2156 – –
358Y 1 *** Plug, Impeller 2156 – –
360C 1 *** Gasket—Thrust End Cover Buna
360D 1 Gasket—Frame-to-Adapter Buna
360Q 1 Gasket—Gland-to-Stuffing Box
Cover
Material varies
361A 1 Retaining Ring Steel
370 **** Bolt—Adapter to Case 2228
370B 4 Bolt—Frame-to-Adapter 2210
370C ** Clamp Bolt —Bearing Housing 2210
370D **l Jack Bolt—Bearing Housing 2210
370F 2 Bolt—Frame Foot to Frame 2210
370H 2 Stud—Stuffing Box Cover-to-Adapter 2228
370Y 2 Bolt—Cap Casing to Support – – –
371C 6 *** Cap Screw-End Cover to Bearing
Housing
2210
382 1 Bearing Lockwasher Steel
383 1 Mechanical Seal Material varies
400 1 Coupling Key 2210
408A 1 Plug—Oil Drane 2210
408H 4 Plug—Oil Mist Connection 2210
408J 1 Plug—Oiler 2210
408L 1 Plug—Oil Cooler Inlet 2210
408M 1 Plug—Oil Cooler Outlet 2210
408N 1 Plug—Sight Glass 2210
412A 1 O-Ring, Graphoil Impeller – – –
418 3 Jack Bolt—Adapter-to-Case 2228
423 3 Jam Nut—Bearing Housing Jack Bolt 2210
423B 2 Hex Nut—Stuffing Box Cover to
Adapter
2228
Parts Listings and Cross-Sectional Drawings
138 Model 3196 i-FRAME Installation, Operation, and Maintenance Manual
