ITT 3196 i-FRAME - Page 141

Item Quantity Part name Pump Material (3196,
HT 3196, CV 3196,
3796)
Pump Material (NM
3196)
Pump Material
(3198)
All Titanium Vinylester D.I./Teflon
428 1 Gasket, Plug
Teflon
437 1 Lockwasher, Casing to Support – – –
458Y 1 *** Plug, Impeller 2156 – –
469B 2 Dowel Pin—Frame-to-Adapter Steel
494 1 Tube Element, Finned Cooled 304SS / Copper
496 1 O-Ring Bearing Housing Buna N
412A 1 O-Ring—Impeller Viton
497F 1 O-Ring—Outboard Labyrinth Rotor Viton
497G 1 O-Ring—Outboard Labyrinth Stator Viton
497H 1 O-Ring—Inboard Labyrinth Rotor Viton
497J 1 O-Ring—Inboard Laybrinth Stator Viton
497L 1 O-Ring Internal (inboard) Viton
497N 1 O-Ring Internal (outboard) Viton
503 1 Adapter Ring 1013
529 1 Lockwasher—Frame Foot-to-Bearing
Frame
Steel
555 1 Tube, Finned Cooling Assembly 304AA / Copper
555A 1 Tube, Ftg Male (Frame Cooling) Brass
555B 2 Connector, Thermocouple (Frame
Cooling)
Brass
555C 2 Elbow, Female (Frame Cooling) Brass
555D 1 Conn TC Sealed PWR Cast iron
761B 1 i-ALERT
™
Condition Monitor Stainless steel/epoxy
Table 28: Key to table symbols
–
Not applicable
* Only applicable for HT 3196
** 3 for STi, MTi, LTi
4 for XLT-i, i17
*** XLT-I and i17 only
**** 4 for 6 in. STi
8 for 8 in. STi and MTi
16 for 13 in. MTi, LTi , XLT-I
24 for 15 in. XLT-I
12 for 10 in. MTi, LTi , i17
Table 29: Material-code reference
Material Goulds material
code
ASTM Din ISO JIS
Cast Iron 1001 A48 CLASS 20
Ductile Iron 1012 A395 Gr60-40-18
Ductile Iron 1013 A536 Gr60-42-10
CD4MCu 1041 A744 CD4MCU
Parts Listings and Cross-Sectional Drawings
Model 3196 i-FRAME Installation, Operation, and Maintenance Manual 139
