22
IVT 495 TWIN 9518799
Dur. hot water GT3:1
50,0º
Room GT5
20,0º
Checking temperatures, cont.
Flow temperature
Flow, heating GT1 shows the temperature that the
heat pump supplies to the heating system.
Outdoor temperature
Outdoor GT2 shows the outdoor air temperature.
Duration hot water temperature
Dur. hot water GT3:1 shows the temperature that
the heat pump supplies to the hot water tap system.
Indoor temperature
(Requires a room sensor, which is an accessory.)
Room GT5 shows the indoor temperature.
Other temperatures
A further four temperatures are shown: Dur. hot
water GT3:2, Heating water GT3:3, Compressor
GT6 and HTFcoll GT10. These are solely for the
heat pump’s internal usage.
Flow, heating GT1
23,8° ( 23,0°)
The actual temperature is shown
here.
The calculated temperature,
which is dependent on the
outdoor temperature and
chosen heat curve, is shown
here.
Outdoor GT2
14,0º
