IVT 495 TWIN User Manual

31
IVT 495 TWIN 9518799
Important information!
The suction pipe
should be cold.
The pressure pipe
should be hot.
Switch conductors T2 and T3.
It is important that the compressor in this model
operates in the right direction. If it operates in the
wrong direction there is a high sound level and no
output. You can tell that the compressor is
operating in the right direction if the suction pipe
to the compressor is cold and the pressure pipe
out from the compressor is hot. NOTE: The
pressure pipe could be extremely hot, so be
careful! If the compressor is operating in the
wrong direction, switch conductor two (T2) and
three (T3) on the underside of the motor
protection in the electric box.
For the installer
INSTALLER
