Jackson DELTA Series - Electrical Requirements

4
Electrical Requirements:
Wash Motor HP 1
Sustaining Heater kW 2
All electrical ratings provided in this manual are for reference only. Always
refer to the machine data plate to get exact electrical information for this
machine. All electrical work performed on machines should be done in
accordance with applicable local, state, territorial, and national codes.
Work should only be performed by qualied electricians and authorized
service agents.
Note that all electrical wiring used in the Delta series of machines must be
rated, at a minimum, for 212 °F (100 °C), and that only copper conductors
must be used.
*The Delta 5-E is designed so the wash motor is never running when the
sustaining heater is on. Total Amps is based on the higher of the two loads.
Delta 5-E
Electrical Characteristics
VOLTS 115
PHASE 1
FREQ 60
WASH
MOTOR
AMPS
10.0 A
SUST.
HEATER
AMPS
16.0 A
TOTAL
LOAD
16.0 A*
MCA 18.5 A
MOP 25 A
NOTICE
i
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
