Jackson DELTA Series - Sustaining Heater

33
SUSTAINING HEATER
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Heater Tank 05700-003-25-40
2 1 Heater Gasket 05330-011-61-34
3 1 Sustaining Heater 04540-002-45-13
4 4 Lockwasher, Split 5/16” 05311-275-01-00
5 4 Nut, Hex 5/16-18 05310-275-01-00
6 2 Nut, Lock 6-32 Hex with Nylon Insert 05310-373-03-00
7 2 Spacer, 1/4” OD x 9/32” 09330-004-34-91
8 1 Thermostat, Elan Electric (Dual) 06685-004-17-27
9 1 Cover, Heater Box 05700-004-34-90
10 1 Decal, Warning to Disconnect Power 09905-004-08-16
11 1 Probe, Thermistor 06685-004-17-26
12 1 Probe Fitting, Thermostat 05310-924-02-05
13 1 Washer, Thermostat Probe Fitting 05700-001-23-96
1
7
2
6
5
3
4
8
9
10
11
12
13
