CONTROL BOX
PARTS
ITEM QTY DESCRIPTION PART NUMBER
Complete Control Box Assembly 05700-003-36-55
1 1 Control Box Weldment 05700-003-09-42
2 1 Control Box Cover 05700-003-30-54
3 1 Decal, Warning - Disconnect Power 09905-004-08-16
4 4 Screw, 10-32 x 1/2’’ Long, Phillips Tusshead 05305-011-39-36
5 1 Decal, Peri-pump Prime 09905-003-32-56
6 1 Switch, Delime/Normal 05930-301-21-18
7 1 Detergent/Rinse-aid Pump Prime Switch 05930-011-35-27
8 1 Sanitizer Pump Prime Switch 05930-111-38-21
9 1 Locknut, 1/4-20 SS Hex with Nylon Insert 05310-374-01-00
10 1 Washer, 1/4-20 SS 05311-174-01-00
11 2 Contactor 05945-109-05-69
12 1 Timer, 8 Cam 05945-111-35-32
13 1 Decal, Cam Timer 09905-011-37-21
14 4 Fitting, Conduit, Heyco 1/2’’ 05975-011-49-03
15 1 Fitting, 1/2’’ Straight Snap-in 05975-003-33-27
16 5 Clamp, 5/8” Nylon 04730-011-39-01
17 2 Relay, 2-Pole 05945-111-35-19
18 1 Terminal Board 05940-021-94-85
19 1 Harness, Switch Panel 05700-003-35-37
20 1 Fitting, 1/2’’ 90-Degree Snap-in 05975-003-33-28
21 1 Conduit, 1/2” x 40” 05700-003-35-48
22 1 Cycle Counter 05990-111-35-38
23 2 Screw, 4-40 x 1/4” Phillips Pan Head 05305-002-32-38
24 1 Terminal Board 05940-002-78-97
25 1 Terminal Board 05940-001-97-91
26 1 Decal, Terminal Board 8-Position 09905-003-09-30
27 16 Locknut, 10-24 SS Hex with Nylon Insert 05310-373-01-00
28 6 Locknut, 6-32 SS Hex with Nylon Insert 05310-373-03-00
29 1 Harness, Wash Pump 05700-003-35-34
30 1 Harness, Drain Solenoid 05700-003-35-36
31 1 Harness, Peri-pump 05700-003-35-35
32 1 Conduit, 1/2” x 17” 05700-003-35-49
To Next Page
