28
TUB
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Tub Weldment 05700-003-09-51
2 1 Lower Manifold Weldment 05700-002-45-51
3 2 Manifold Gasket 05700-111-35-03
4 1 Drain Seat Insert 05700-004-37-18
5 1 Spillway Gasket 05700-111-34-52
6 1 Spillway Weldment 05700-003-52-13
7 23 Locknut, 1/4-20 SS Hex with Nylon Insert 05310-374-01-00
8 1 Manifold O-Ring 05330-111-35-15
9 1 Modified Casting Wedge 09515-011-46-61
10 2 Bolt, 3/8-16 x 1 1/4” SS 05305-276-10-00
11 2 Washer, 3/8” Bevel-Square Iron 05311-011-35-36
12 2 Lockwasher, 3/8” 05311-276-01-00
13 2 Nut, 3/8-16 SS Hex 05310-276-01-00
14 1 Complete Wash Arm Assembly 05700-021-39-23
14a 1 Wash Arm End-cap 05700-003-31-59
15 1 Sump Strainer 05700-002-60-50
16 1 Stand Pipe 05700-004-19-50
17 1 Complete Drain Link Assembly 05700-002-45-52
17a 1 Drain Link 05700-002-40-83
17b 1 Nut, Hex, 5/16-18 05310-275-01-00
17c 1 Drain Link Connector 05700-002-38-10
18 1 Hair Pin, 1/8” to 1” 05315-011-60-09
19 1 Fill Tube Weldment 05700-002-45-61
20 18 Washer, 1/4-20 ID 05311-174-01-00
21 3 Chemical Tube Grommet 05325-002-42-65
22 2 Complete Door Pivot Plate Assembly 05700-003-54-46
23 3 Bolt, 1/4-20 x 1/2” 05305-274-02-00
24 6 Screw, 1/4-20 x 5/8” 05305-274-24-00
25 1 Air-gap Weldment 05700-003-23-48
26 1 Halo Assembly 05700-003-23-49
26a 1 Halo Weldment 05700-003-16-64
26b 4 Spray Nozzle and Receptacle 04730-002-55-61
27 1 Gasket, Air-gap 05330-003-24-17
