A GO*BOX is a kit of the most needed parts for a particular model or model family to successfully effect a repair in the first call
90% or more of the time.
The following components may be ordered together using the following Mfg. No.: 06401-002-15-00.
ITEM QTY DESCRIPTION Mfg. No.
1 1 Contactor, Rinse/Wash Heater 05945-109-01-69
2 1 Contactor, Wash Motor 05945-002-74-20
3 1 Gauge, Pressure, 0-100 PSI 06685-111-88-34
4 1 Thermometer, 96" Capillary 06685-111-68-49
5 1 Thermometer, 48" Capillary 06685-111-68-48
6 1 Thermostat, Rinse Operating 06401-140-00-33
7 1 Thermostat, Wash Operating 06401-140-00-32
8 1 Thermostat, Hi-Limit 05930-011-49-43
9 1 Liquid Level Control 06680-200-08-21
10 1 Probe, water level sensing 06680-200-02-68
11 1 Magnet,Door 05930-111-51-68
12 6 Glide, Door Edge 05700-111-33-59
13 2 O-Ring Wash Manifold 05330-111-35-15
14 1 Relay,Control 240V 50/60Hz 05945-111-47-51
15 1 Seal, Mechanical Pump (S/S Pumps) 05330-002-34-22
16 1 O-Ring, Wash Pump Gasket 05330-002-81-83
17 1 Switch, Door, Magnetic Reed 05930-111-51-69
18 2 Snap Ring, Retaining, Rinse Arm 05340-112-01-11
19 1 Bearing Assembly, Wash Arm 05700-021-35-97
20 1 Switch, Power Push Button 05930-002-29-13
21 1 Timer, Universal 05945-003-33-10
22 4 Washer, Rinse Arm Nylatron 05330-011-42-10
23 1 Vacuum Breaker 3/4" Brass 04820-002-53-77
24 1 Valve, Solenoid, 3/4", 220V 04810-100-03-18
* 1 Pump & Motor Assembly, S/S 06105-002-69-78
Special pricing available when purchased with above GO*BOX. Call for details.
Tempstar LT/NB/S/SDS Technical Manual 7610-011-86-35
Issued: 12-07-2007 Revised: N/A
SECTION 5: PARTS SECTION
GO*BOX COMPONENTS
57
