WAREFORCE UH/UL 30 Technical Manual (07610-003-67-21)
WAREFORCE™ UL 30 CHEMICAL FEEDER PUMP ASSEMBLY (CONTINUED)
Page Created: 04-01-2011
Revised: 03-11-2013
Item QTY Description Part Number
1
1 Peri Pump Plate Channel 05700-003-53-25
2 2 Switch, Pressure 06685-003-36-13
3 2 Bracket, Pressure Switch 05700-003-53-03
4 2 Locknut, 10-24 with Nylon Insert 05310-373-01-00
5 2 Motor, 36 RPM 115V 04320-111-35-14
6 1 Motor, 14 RPM 115V 04320-111-35-13
7 2 Peri Pump Kit (Black Roller)
04320-002-87-63
8 3 Chemical Tube Stiffener 05700-002-66-49
9 1 Peri Pump Kit (White Roller) Not Shown 04320-002-83-90
10 3 Tube, Tygoprene 05700-003-22-89
11
1
Wye, 1/4” Barbed PVDF
04730-003-36-14
12 4 5/16 ID Clear Tube 05700-003-53-26
13 1 Red Tube 1/4” X 100” 05700-003-03-45
14 1 White Tiber 1/4” X 100” 05700-003-20-67
15 1 Blue Tube, 1/4” X 48” 05700-002-62-11
16 1 Blue Tube, 1/4” X 100” 05700-003-20-68
17 1 Red Tube, 1/4” X 48” 05700-002-62-12
18 1 White Tube, 1/4” X 48” 05700-002-62-13
19 - Tye Wrap 05945-602-01-16
