WAREFORCE UH/UL 30 Technical Manual (07610-003-67-21)
WAREFORCE™ UH 30 THERMOSTAT & RINSE TANK ASSEMBLY
Page Created: 04-06-2011
Revised: 03-11-2013
Thermostat
05930-003-06-48
Complete Rinse Tank Assembly
(AVENGER HT 208-230V)
05700-003-31-94
Complete Rinse Tank Assembly
(AVENGER HT 480V)
05700-003-37-78
Fitting, 1 /4" Imperial Brass
05310-924-02-05
Rinse Tank Weldment
05700-003-31-95
Heater:
208-230 Volt 04540-111-43-21
480 Volt 04540-002-29-82
Gasket, Heater
05330-011-47-79
Locknut, 1 /4"-20 S/S
Hex with Nylon Insert
05310-374-01-00
Dielectric Cover
05700-001-40-50
Lock Washer, 5 /16" Split
05311-275-01-00
Nut, 5 /16"-18 S/S Hex
05310-275-01-00
