Jackson WAREFORCE UH 30 - Chemical Feeder Pump Components

35
WAREFORCE UH/UL 30 Technical Manual (07610-003-67-21)
CHEMICAL FEEDER PUMP COMPONENTS
Page Created: 04-01-2011
Revised: 03-11-2013
Motor, 14 RPM 115V
Rinse Aid Feeder Pump
04320-111-35-13
Tygoprene Tube
05700-03-22-89
Motor, 14 RPM 240V
Rinse Aid Feeder Pump
04320-111-47-46
Motor, 36 RPM 115V
Detergent/Sanitizer Feeder Pump
04320-111-35-14
Motor, 36 RPM 240V
Detergent/Sanitizer Feeder Pump
04320-111-47-47
Roller, Black
04320-111-65-27
Roller, White
04320-002-82-28
Front Housing
04320-111-37-08
Screw, 6-32 X
3
4
" Phillips Pan
Head (4 Per)
05305-011-37-05
Screw, 8-32 X
1
2
" Phillips
Flat Head (2 Per)
05305-011-37-06
Screw, 8-32 X 3/8" Phillips Pan
Head (2 Per)
05305-011-37-07
Rear Housing
04320-111-37-09
