WAREFORCE UH/UL 30 Technical Manual (07610-003-67-21)
WASH MOTOR/DRAIN PLUMBING/WAREFORCE™ UL 30 WASH MANIFOLD ASSEMBLY
Item QTY Description Part Number
1 1 HUB, DISCHARGE MACHINED (WAREFORCE™ UH 30 SHOWN) 05700-021-37-90
1A 1 LOWER, WASH MANIFOLD (WAREFORCE™ UL 30) 05700-021-52-80
2 1 GASKET, MANIFOLD 05330-200-23-00
3 1 NUT, JAM 1-1/2”-12 NPT 05700-000-86-23
4 4 HOSE CLAMP, 1-5/16”-2 1/4” #28 04730-719-01-37
5 1 HOSE, 1-1/4” X 2-1/4” REINFORCED 05700-011-44-48
6 1 HOSE, BOTTOM MANIFOLD PUMP 05700-001-22-92
7 1 GASKET, SUCTION ADAPTOR 05330-003-32-82
8 1
2
2
CASTING, SUCTION ADAPTOR
WASHER, S/S 1/4”-20 I.D.
LOCKNUT, 1/4”-20 S/S
09515-031-39-86
05311-174-01-00
05310-374-01-00
9 3 CLAMP, 3/16” TO 1-1/2” 04730-719-06-09
10 1 HOSE, 8” STRAIGHT DRAIN 04720-003-27-95
11 1 HOSEBARB, 1” X 3/4” NPT POLYPROPYLENE 04730-011-65-86
12 1 SPACER, DRAIN VALVE 05700-003-31-93
13 1 BRACKET, DRAIN VALVE SUPPORT 05700-003-31-74
14 1 HOSE, 1” I.D. X TEN FEET LONG 05700-011-39-72
15 1 HOSEBARB, 90 DEGREE 1” X 3/4” NPT 04730-011-65-87
16 2 O-RING, MANIFOLD 05330-111-35-15
17 1 TUBE, WASH MANIFOLD 05700-002-13-75
18 1 UPPER WASH MANIFOLD 05700-031-34-82
19 1
1
BRACKET, MANIFOLD TUBE POSITIONING
LOCKNUT, 1/4”-20 S/S
05700-011-34-63
05310-374-01-00
