Parts-23
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
1001273 1 Handle 518 Units only
1 1001266 1 Handle 522 Units only
1 1001275 1 Handle 526 Units only
2 1001250 1 Handle Loop
3 3002047 2 Bracket
4 434029 2 Screw, 1/4-20 x 1” Socket Head
5 366708 2 Flange Bearing
6 1001977 1 Pivot Assembly
7 1000634 1 Brake Handle
8 3002480 1 Tension Spring
9 3002001 1 Brake Knob
10 366741 2 Brake Cable
11 366743 1 Throttle Cable
12 454008 2 Spring Washer
13 3002477 1 Clutch Cable
14 2000067 1 Brake Clutch Lever
15 461181 1 Groove Pin, 3/16 x 3/4”
16 446142 3 Lockwasher, 3/8 Heavy
17 434023 2 Screw, 1/4-20 x 1-1/4” Socket Head
18 3002179 1 Handle Loop
19 1001007 1 Latch
20 3004259 1 Channel Loop
21 400108 4 Screw, 1/4-20 x 3/4” Hex Head
22 446130 8 Lockwasher, 1/4 Heavy
23 443102 2 Nut, 1/4-20 Hex
24 458006 2 Retaining Ring
25 400268 1 Screw, 3/8-16 x 1-3/4” Hex Head
26 444708 2 Locknut, 1/4-20 Center
27 443110 4 Nut, 3/8-16 Hex
28 460026 2 Cotter Pin, 1/8 x 3/4”
29 1001292 2 Bracket
30 3002078 1 Throttle Stop
31 2809900 1 Spring, Left Side Torsion
32 2809901 1 Spring, Right Side TOrsion
33 400262 2 Screw, 3/8-16 x 1” Hex Head
34 365660 2 Grommet
35 2810676 2 Handle Stop
36 453011 2 Flat Washer, 3/8
37 366745 2 Bolt
38 447224 2 Lockwasher, 5/8 Internal Tooth
39 455012 2 Flat Washer, 1/2
40 460014 1 Cotter Pin, 3/32 X 3/4”
41 461462 1 Clevis Pin, 3/8 x 1 1/16”
42 443828 2 Nut, 5/8-18 Hex Jam
To Next Page
