Parts-25
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
5003040 1 Round Grip
2 366768 2 Throttle Knob
3 473137 2 Wire Tie
4 1003413 1 Brake Handle
5 1001860 1 Latch
6 1003019 1 Control Handle
7 3006858 1 Throttle Control
8 3002078 1 Throttle Stop
9 400108 2 Screw, 1/4-20 x 3/4” Hex Head
10 446130 2 Lockwasher, 1/4 Heavy
11 443102 4 Nut, 1/4-20 Hex
12 3003676 2 Flanged Bearing
13 454008 1 Spring Washer
14 3003992 1 Spring Return
15 1003229 1 Handle
16 3004971 1 Decal, Clutch
17 461457 1 Pivot Pin
18 460014 3 Cotter Pin, 3/32 x 3/4”
19 400266 2 Screw,3/8-16 x 1-1/2” Hex Head
20 443110 4 Nut, 3/8-16 Hex
21 2000067 2 Brake Lever
22 3006857 2 Brake Cable
23 461181 3 Groove Pin, 3/16 x 3/4”
24 3006856 1 Clutch Cable
25 3004399 1 Pivot Shaft
26 461466 1 Clevis Pin, 3/8 x 2-1/8”
27 461468 1 Clevis Pin, 3/8 x 1-1/2”
28 3002753 1 Decal, Parking Brake
29 3002755 1 Decal, Throttle
30 3004609 1 Cable Cover
31 409951 3 Screw, #8-32 x 3/8” Truss Head
32 400112 1 Screw, 1/4-20 x 1” Hex Head
33 365660 2 Grommet
34 2810676 2 Handle Stop
35 400262 2 Screw, 3/8-16 x 1” Hex Head
36 446142 2 Lockwasher, 3/8 Heavy
37 453011 2 Flat Washer
38 366745 2 Bolt
39 447224 2 Lockwasher, 5/8 Internal Tooth
40 443828 2 Nut, 5/8-18 Hex
41 458006 2 Retaining Ring
42 2809900 1 Spring, Left Side Torsion
43 2809901 1 Spring, Right Side Torsion
44 455012 2 Flat Washer, 1/2
To Next Page
