Parts-29
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
443102 1 Nut, 1/4-20 Hex
2 400112 1 Screw, 1/4-20 x 1” Hex Head
3 443112 1 Nut, 3/8-24 Hex
4 446136 4 Lockwasher, 5/16
5 443108 2 Nut, 5/16-24 Hex
6 555795 1 Split Clutch Disc
7 307456 1 Washer, Cup
8 352726 2 Bushing
9 460052 1 Cotter Pin, 3/16 x 1-1/2”
10 446130 1 Lockwasher 1/4 Heavy
11 3000966 1 Spring
12 366800 1 Clutch Spring
13 366799 1 Clutch Spring
14 400228 2 Screw, 5/16-24 x 1-1/4” Hex Head
15 3005380 1 Clutch Fingers
16 132930 1 Clutch Arm Assembly
17 3000914 1 Bolt, Special
18 366742 1 Clutch Pin
19 400104 AR Screw, 1/4-20 x 1/2” Hex Head
20 1000014 1 Clutch Shaft (518A) 62281 Only
20 1000842 1 Clutch Shaft (522A and 522TA) 62282 and 62283 Only
20 1000015 1 Clutch Shaft (526A) 62284 and 62285 Only
21 2000004 1 Sliding Disc
22 367365 1 Bearing
23 366689 1 Washer
24 463113 1 Key
25 366686 1 Wear Sleeve
26 400188 2 Screw, 5/16-18 x 1” Hex Head
27 444708 AR Locknut, 1/4-20 Center
28 458113 2 Retaining Ring
29 366685 1 Grease Seal
30 366684 1 Bearing
31 366648 1 Grease Seal
32 471223 1 Grease Fitting
33 241831 1 Housing
34 453009 4 Flat Washer, 5/16
35 3007847 1 Pulley, 7 Rib Micro V
36 367082 1 Key, 3/16 Square x 3/4”
37 366653 1 Spacer
38 446142 3 Lockwasher, 3/8
39 400262 1 Screw, 3/8-16 x 1” Hex Head
40 444718 2 Locknut, 5/16-18 Center
41 1003718 1 Clutch Cover
42 3008164 1 Decal, Jacobsen
To Next Page
