Parts-31
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
REF 1 Reel See 1.1
2 2811122 1 Frame, R.H. Side
3 2811121 1 Frame, L.H. Side
4 5002727 1 Reel Clutch
5 471217 1 Grease Fitting
6 1000447 1 Bearing Housing
7 366650 1 • Seal
8 471214 1 • Grease Fitting
9 545940 1 • Bushing
10 1000446 1 Bearing Housing
11 366650 1 • Grease Seal
12 366649 1 • Grease Seal
13 545940 1 • Bushing
14 446142 1 Lockwasher, 3/8 Heavy
15 446136 3 Lockwasher, 5/16 Heavy
16 366653 1 Washer
17 3004369 1 Spring Retainer
18 3004368 1 Spring Retainer
19 434036 3 Screw, 5/16-18 x 1-1/4” Socket Hd.
20 164041 1 Seal Carrier
21 366648 1 • Grease Seal
22 367029 1 Nut, 3/4-16 Hex Nylock Jam
23 366651 1 Bolt
24 400114 2 Screw, 1/4-20 x 1-1/4” Hex Head
25 3006061 1 Spring
26 434028 3 Screw, 1/4-20 x 3/4” Socket Head
27 446130 5 Lockwasher, 1/4 Heavy
28 364900 1 Nut
29 363047 1 Spring
30 500543 2 Bearing Cup and Cone
31 304745 1 Washer
32 2000064 1 Cover
33 366645 1 Spacer
34 2811185 1 Pulley
35 365229 1 • Bearing With Seal
36 366652 1 • Bearing
37 458461 1 • Snap Ring
38 366646 1 Spacer
39 345556 1 Key, 1/8 Square x 1”
40 340462 1 Spacer
41 320774 2 Key, 3/16 Square x 1-1/4”
To Next Page
