Jacobsen 62282 - Page 121

Parts-33
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
REF 1 Bedknife Backing See 1.1
2 REF 1 Bedknife See 1.1
3 REF 1 Rear Crossbar See 1.1
4 REF 1 Kickstand See 1.1
5 REF 1 Front Crossbar See 1.1
6 3001600 2 Bedknife Block
7 366727 2 Rod
8 446142 17 Lockwasher, 3/8 Heavy
9 446136 6 Lockwasher, 5/16 Heavy
10 400258 12 Screw, 3/8-16 x 3/4” Hex Head
11 400262 2 Screw, 3/8-16 x 1” Hex Head
12 366653 6 Spacer
13 366709 2 Spring
14 367512 2 Spacer
15 400264 1 Screw, 3/8-16 x 1-1/4” Hex Head Used on 518 Only
16 446130 1 Lockwasher, 1/4 Heavy Used on 518 Only
17 444850 3 Nut, 3/8-16 Center Lock Jam
18 434051 3 Screw, 5/16-18 x 1/2” Socket Head
19 443810 4 Nut, 3/8-16 Hex Jam
20 400268 2 Screw, 3/8-16 x 1-3/4” Hex Head
21 3001644 1 Weight Used on 518 Only
22 365501 2 Bolt, Bedknife Shoe
23 454017 2 Shim, Bedknife Shoe
24 366796 2 Kickstand, Mounting Bracket
25 443110 2 Nut, 3/8-16 Hex
26 3009138 AR Screw, 1/4-20 x 3/4 Soc. Hd.
27 400114 1 Screw, 1/4-20 x 1-1/4” Hex Head Used on 518 Only
28 400264 2 Screw, 3/8-16 x 1-1/4 Hex Head
29 400260 3 Screw, 3/8-16 x 7/8” Hex Head
30 2811102 1 Decal, Warning
31 REF 1 Serial Plate
32 364164 1 Spring
33 366726 4 Bolt, Special
