Jacobsen 62282 - Page 123

Parts-35
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
503685 1 Pulley, 80 Tooth
2 367554 2 • Needle Bearing
3 1000056 1 Traction Clutch
4 366725 1 Flanged Bushing
5 443106 2 Nut, 5/16-18 Hex
6 5002447 1 Pulley, 18 Tooth
7 2000148 1 Bearing Bracket
8 3001273 1 Shaft
9 446142 3 Lockwasher, 3/8 Heavy
10 443110 2 Nut, 3/8-16 Hex
11 443102 7 Nut, 1/4-20 Hex
12 401018 1 Screw, 5/16-18 x 3-1/4” Hex Head
13 434031 1 Screw, 1/4-20 x 3/4” Socket Head
14 359864 AR Washer
15 367553 1 Needle Bearing
16 400262 2 Bolt, 3/8-16 x 1”
17 400188 1 Screw, 5/16-18 x 1” Hex Head
18 453011 2 Washer
19 2810713 1 Belt, 7 Rib Micro V
20 2811363 1 Belt, 112 Tooth
21 2811071 1 Belt, 80 Tooth
22 458006 2 Retaining Ring
23 2809667 1 Bracket, Idler Spring
24 2809669 1 Spring, Idler
25 400116 1 Screw, 1/4-20 x 1-1/2” hex Head
26 2810550 1 Bracket, Idler
27 364144 2 Bushing
28 400106 2 Screw, 1/4-20 x 5/8” Hex Head
29 2809665 1 Arm, Idler
30 344545 1 Bearing
31 2809666 1 Pulley, Idler
32 458015 1 Retaining Ring
33 446128 1 Lockwasher, 1/4
34 400254 2 Screw, 3/8-16 x 1/2” Hex Head
35 3009434 1 Bracket, Belt Adjusting
