Parts-37
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
503638 1 Belt Cover
2 2811092 1 • Decal, Warning
3 3001792 1 • Decal, Reel Clutch
4 3000660 1 Traction Clutch Lever
5 443102 3 Nut, 1/4-20 Hex
6 446130 12 Lockwasher, 1/4 Heavy
7 220317 1 Shifter Housing
8 400112 5 Screw, 1/4-20 x 1-1/4” Hex Head
9 400106 6 Screw, 1/4-20 x 5/8” Hex Head
10 366707 1 Ball Bearing
11 366715 2 Spacer
12 446136 2 Lockwasher, 5/16 Heavy
13 400196 2 Screw, 5/16-18 x 2” Hex Head
14 366710 1 Cover
15 422522 4 Set Screw, 3/8-16 x 1/2” Socket Hd.
16 343850 4 Ball, 1/4” Diameter
17 343848 2 Spring
18 339910 2 “O”Ring
19 3004402 1 Shifter Shaft
To Next Page
