Parts-39
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1 3009185 1 Grass Shield (518A) Used on 62281 Only
1 3008674 1 Grass Shield (522A) Used on 62282 and 62283 Only
1 3009186 1 Grass Shield (526A) Used on 62284 and 62285 Only
2 3000053 2 Plate
3 241827 1 L.H. Catcher Mounting Bracket
4 241828 1 R.H. Catcher Mounting Bracket
5 2000072 2 Roller Bracket
5 2000040 2 Roller Bracket Used on 62285 Only
6 3005692 2 Adjuster Knob
7 343616 2 Stud
8 366852 2 Spacer
9 461339 2 Pin, 1/4 x 1-1/4”
10 364441 2 Washer
11 446136 2 Lockwasher, 5/16 Heavy
12 443106 2 Nut, 5/16-18 Hex
13 441674 2 Carriage Bolt 5/16-18 x 1-3/4”
14 3008974 4 Grommet
15 443102 4 Nut, 1/4-20 Hex
16 445781 2 Nut, 5/16-18 Whiz Lock
17 352727 2 Screw, 1/4-20 x 7/8” Square Head
18 400112 2 Screw, 1/4-20 x 1-1/4” Hex Head
19 453023 2 Flat Washer
20 444718 2 Locknut, 5/16-18 Center
21 441677 2 Carriage Bolt, 5/16-18 x 1-1/4”
22 441614 2 Carriage Bolt, 5/16-18 x 1”
To Next Page
