Parts-43
> Change from previous revision
GREENS KING 500A SERIES
Item Part No. Qty. Description Serial Numbers/Notes
1
554847 2 Tire
2 5002905 2 Wheel, Gray
3 1000476 1 R.H. Hub
4 338766 1 • Bearing
5 366705 2 • Grease Seal
6 164056 2 Brake Band
7 132663 1 Brake Mounting Bracket
8 132658 1 Seal Housing
9 365743 1 • Grease Seal
10 471214 1 • Grease Fitting
11 164063 1 Brake Mounting Bracket
12 271920 2 Wheel Spacer
13 1000477 1 L.H. Hub
14 338766 1 • Bearing
15 366705 2 • Grease Seal
16 366717 2 Clutch Sleeve
17 445801 2 Nut, 5/8-18 Hex Jam Lock
18 434049 6 Screw, 5/16-18 x 2” Socket Head
19 366718 2 Latching Collar
20 366697 4 Bushing
21 446136 4 Lockwasher, 5/16 Heavy
22 400188 2 Screw, 5/16-18 x 1” Hex Head
23 360111 2 Valve
24 361451 1 Washer Left Side Only
25 415513 2 Set Screw, 1/4-20 x 1/2”
26 366742 2 Brake Band Pin
27 446130 2 Lockwasher, 1/4 Heavy
28 400108 2 Screw, 1/4-20 x 3/4” Hex Head
29 366737 2 Spacer
30 434032 2 Screw, 5/16-18 x 1-3/4” Socket Head
31 366716 6 Spacer
32 366719 2 Latch
33 443106 1 Nut, 5/16-18 Hex
34 366704 2 Spring
35 452004 12 Flat Washer, 5/16
36 444718 6 Locknut, 5/16-18 Center
To Next Page
