CHAPTER 1. GENERAL INFORMATION
11
1
CHAPTER 1. GENERAL INFORMATION
1. MODEL NAME AND IDENTIFICATIONS NUMBERS
a. Model name plate
The model name plate, which gives the model
name, type, production serial number, and pro-
duction year of the machine, is located on the
right-hand side of the chassis.
Fig. 1-1
(1) Model
(2) Type
(3) Production serial number
(4) Production year
Fig. 1-2
(A) Model name plate
(B) Engine plate
(C) Punched model name and serial number on
the right side of the chassis
SXG323 H000001
b. Engine model name and serial number
• The engine name is cast into the left-hand side
wall of the cylinder block.
• The serial number is punched into the left-hand
side wall of the cylinder block.
Fig. 1-3
(1) Model
(2) Displacement
(3) Production serial number
1
2
3 4
SXG323H
E42
510kg
14.0kW/2600min
-1
C
Chassis production serial number
Manufacturer’s model name
112
123
1
2
3
