CHAPTER 6. DISASSEMBLY AND REASSEMBLY OF GEAR BOX
27
6
2. DISASSEMBLY AND REASSEMBLY
a. Detach the gear case from mower deck.
b. Remove the bolts and metal cover.
c. Remove the gear and bearing.
d. Remove the oil seal and snap spring
e. Remove the bevel gear
f. Inspect the disassembled parts for items men tined
below and replace defective parts with new ones.
- Abnormal wear and flaws of bevel gears.
- Wear or abnormal deformation of oil seals: as oil
seal are consumable parts, disassembled ones shoul
