SERVICE MANUAL FOR SXG323&326
12
Model SXG 326 H SXG 323 H
E42 GE42 E42 GE42
Dimensions Overall length 2110 mm (83.1 in.)
Overall width 1170 mm (46.1 in.) 1100 mm (43.3 in.)
Overall height 1320 mm (52 in.) 1290 mm (50.8 in.)
Weight
525 kg (1157
lb.)
530 kg (1168
lb.)
510 kg (1124 lb.) 515 kg (1135 lb.)
Engine Model E3112-G07 E3112-G06
Type Vertical, Water-cooled, 4-cycle, diesel
Combustion
chamber
Swirl chamber type
No, of cylinders 3
Total
displacement
1123
Output (net)
15.4 kw (21ps)
2600 min-1 (rpm)
14.0 kw (19 ps)
2600 min-1 (rpm)
Fuel Diesel fuel
Fuel tank Capacity 21 liters (4.6 imp. gal.)
Transmission
Main
transmission
HST (Hydrostatic transmission)
Rear axle Chain drive
Travel Forward 0-16.5 km/h (0-10.3 mph) 0-14.5 km/h (0-9 mph)
Speeds Reverse 0-10 km/h (0-6.3 mph)
Wheel base 1450 mm (57.1 in.) 1365 mm (53.7 in.)
Wheel Tread Front 930 mm (36.6 in.) 910 mm (35.8 in.)
Rear 860 mm (33.9 in.)
Driving
system
2WD
Steering
system
Power steering
Brake system Dry internal-shoe expanding
No. of Brake 1 (Before dif.) 2 (After dif.) 1 (Before dif.) 2 (After dif.)
Tyre size Front 18 x 8.50-8 16 x 6.5-8
Rear 26 x 10.50-12 23 x 10.50-12
PTO Front 1750 min-1 (rpm)
PTO Clutch Belt tension clutch
Minimum
ground
Lawn mower 140 mm (5.5 in.) 110 mm (4.3 in.)
clearance Mower lift 150 mm (5.9 in.) 130 mm (5.1 in.)
2. SPECIFICATIONS
LAWN MOWER

Jacobsen SXG323 Specifications

General

Brand	Jacobsen
Model	SXG323
Category	Lawn Mower
Language	English
