4-71
4
OPERATION AND ADJUSTMENTS
ARBUS 400
Assembling the PH kit
Spraying volume do kit PH
Nozzles
Pressure
(psi)
Total ow
rate (l/min)
5 nozzles
Working speed (km/h)
2.0 3.0 3.5 4.0 4.5 5.0 5.5 6
Spraying volume (l/ha)
2 DEF-015 (green)
+
3 EF-015 (green)
20 2.20 287 191 164 143 128 115 104 96
25 2.40 313 209 179 157 139 125 114 104
30 2.65 346 230 198 173 154 138 126 115
Application range: 2.30 m
Nozzles
Pressure
(psi)
Total ow
rate (l/min)
5 nozzles
Working speed (km/h)
2.0 3.0 3.5 4.0 4.5 5.0 5.5 6
Spraying volume (l/ha)
2 DEF-015 (green)
+
3 EF-015 (green)
20 2.20 266 177 152 133 118 106 97 89
25 2.40 290 194 166 145 129 116 106 97
30 2.65 321 214 183 160 142 128 117 107
Application range: 2.48 m
Nozzles
Pressure
(psi)
Total ow
rate (l/min)
5 nozzles
Working speed (km/h)
2.0 3.0 3.5 4.0 4.5 5.0 5.5 6
Spraying volume (l/ha)
2 DEF-015 (green)
+
3 EF-015 (green)
20 2.20 248 165 142 124 110 99 90 83
25 2.40 271 180 155 135 120 108 98 90
30 2.65 299 199 171 149 133 120 109 100
Application range: 2.66 m
Nozzles
Pressure
(psi)
Total ow
rate (l/min)
5 nozzles
Working speed (km/h)
2.0 3.0 3.5 4.0 4.5 5.0 5.5 6
Spraying volume (l/ha)
2 DEF-015 (green)
+
3 EF-015 (green)
20 2.20 232 155 133 116 103 93 85 77
25 2.40 254 169 145 127 113 101 92 85
30 2.65 280 187 160 140 124 112 102 93
Application range: 2.84 m
