9
ting should not be altered. Running the circulation pump less than the factory recommended time will
result in issues with water quality maintenance.
Note: The 24-hour primary ltration system also supplies heated water to the spa when the heater
turns on.
5.3 Change Filter Timer Program
• Follow the steps below to access the Change Filter Timer.
Menu button Action Result
Press once
To access the Primary Filtration Menu. The LED will display “PF.”
or
Press
continually
Scrolls through the menus as follows: , , , , ,
, , , ,
Press once
To access the Change Filter Timer. The display on the LED screen will
blink once to indicate that the system is ready to accept changes.
or
Press con-
tinually
To add or subtract days in increments of 10 days. Range is from 0 to 180
days.
Press once
Once the number of days is selected, to conrm your selection.
When time
expires
The LED screen will ash between 0 and
5.4 Secondary Filtration Program
The jets pump 1 activates during the secondary ltration to provide additional skimming. The spa is
programmed with a default setting of SF0 but can be programmed to any of the cycle settings listed
below, Figure 5. These cycles schedule the jets pump 1 to run for a preset amount of time per day, in
addition to normal operation.
Note: During the secondary ltration the jets pump 1, circulation pump and CLEARRAY are activated.
• Follow the steps below to access the program.
Menu button Action Result
Press twice
To access the Secondary Filtration Menu. The LED will display “SF.”
Press once
Activates the system for changes. Last programmed cycle blinks once
on the display.
or
Press
continually
Scrolls through the menus as follows: , , or
Press once
The new programmed cycle will blink twice on the display to conrm
your selection.
No ltration
10 minutes of ltration every 12 hrs
10 minutes of ltration every 8 hrs
10 minutes of ltration every 6 hrs
