JWA WEIGHING SCALE
47
【Relay Module Diagram】
n Relay Output：
Alarm
COM
N.C.
N.O.
HI
COM
N.C.
N.O.
OK
COM
N.C.
N.O.
LO
COM
N.C.
N.O.
n Relay Contact Spec
1A/24VDC，0.5A/125VAC，0.25A/250VDC
