LXi
™
Pool/Spa Heater Installation and Operation Manual Page 51
Section 11. Replacement Parts
11.1 Ordering Information
To order or purchase parts for the LXi pool and
spa heater, contact your nearest Jandy dealer or dis-
tributor. Access the Jandy web site at www.jandy.com
for the nearest service center. If it cannot supply you
with what you need, contact Jandy's Customer Service
Department at 1.707.776.8200, extension 245.
NOTE To order the correct part, it is important that
you state the model number, serial number
and type of gas when applicable. This
information is on the rating plate inside
the heater.
Key
No. Description
Model No. Order
Part No.
Heat Exchanger Components
1 Complete Heat Exchanger (Copper) 250,300,400 R0453303,04,05
2 Tube Assy.(Cu), w/ Hdwr & Gskts 250,400,300 R0453403,05,06
3 Heat Exchanger End Baffl es 250,400,300 R0453503,05,06
4 Front Header, w/ Hdwr & Gskts All R0453600
5 By-Pass Assy, Complete All R0453700
6 Hardware and O-rings, Bypass All R0453800
7 Spring, Bypass All R0453900
8 Coupling Nut Kit, w/ O-ring,
(Set of two)
All R0454000
9* O-ring, Coupling, (Set of two) All R0454100
10 Rear Header, w/ Hdwr & Gskts All R0454200
11 Gasket, Header, Front or Rear,
(Set of 16)
All R0454300
12 Header Drain Plug w/ O-ring (Set of 3) All R0454400
13* Heat Exch. Hardware Kit & Gaskets All R0454500
14 Cap Sensor/Press Switch O-ring All R0455400
15 Return Header Cap & O-ring All R0454600
Gas Components
16 Burner w/ Gasket All R0454700
16 Burner w/ Tap and Gasket All R0454701
17 Manifold, Gas, Nat 250,300,400 R0454803,04,05
17** Manifold, Gas, LP 250,300,400 R0455003,04,05
18 Gas Valve Nat w/ Street Elbow All R0455200
18 Gas Valve LP w/ Street Elbow All R0455300
Exhaust System
19 Flue Collector w/ Gaskets 250,300,400 R0455503,04,05
20 Blower Assy w/ Gasket All R0455600
21 Air Orifi ce Adjust Bracket All R0455700
22 Flue Vent Assy w/ Gasket 250,300,400 R0455803,04,05
23 Outdoor Grill 250/300,400 R0456001,02
24* Vent Hardware Kit All R0456100
25 Flue Box Assy w/ Gasket All R0456200
26* Side Wall Vent Kit 250/300,400 R0467301,02
Electrical
27 Transformer All R0456300
28 Air Pressure Switch All R0456400
29 Temperature Sensor (Regular) All R0456500
29 Temperature Sensor (Salt) All R0477300
30 Gasket, Temperature Sensor All R0456600
31 Plastic Sleeve, Temperature Sensor All R0456700
32 Plug Sensor All R0456800
11.2 Parts List
NOTES:
1. All hardware sets contain all pieces necessary for assembly, including
gaskets.
2. Gaskets and hardware are included in all kits that involve the removal of a
gasket as part of the procedure to replace a part.
* PARTS NOT SHOWN ON KEY VIEW
** MANIFOLD KIT INCLUDES INSTALLED ORIFICES BUT DOES NOT
INCLUDE GAS VALVE
