UMG 508
Supply voltage
Connection capacity of terminal points
Connectable conductors. Only one conductor per terminal point may be connected!
Single wire, multi-wire, fine wire : 0.2 - 2.5mm
2, AWG 24 - 12
Pin terminals, ferrules : 0.25 - 2.5mm
2
Tightening torque : 0.5 - 0.6 Nm,
Insulation length : 7mm
Installation overvoltage category : II
Safeguarding of supply voltage
Circuit breaker : 1A Class CC or circuit breaker
1A Char. C (UL/IEC approved)
Option 240V (Art. no. 52.21.011)
Nominal range : 95V - 240V (50 - 60Hz) or DC 80 - 280V
Working range : +/- 10% of nominal range
Power consumption : max. 6W
Option 130V (Art.no. 52.21.012)
Nominal range : 44V - 130V (50 - 60Hz) or DC 48 - 180V
Working range : +/- 10% of nominal range
Power consumption : max. 6W
