87
UMG 508
8 digital inputs
Maximum counting frequency : 20Hz
Reaction time (Jasic program) : 200ms
Input signal applied : 18V .. 28V DC (typical 4mA)
Input signal not applied : 0 .. 5V DC, current lower than 0.5mA
5 digital outputs, semi-conductor relay, not short-circuit proof.
Switch voltage : max. 54V DC, 27V AC
Switch current : max. 50mAeff AC/DC
Reaction time (Jasic program) : 200ms
Output of voltage drops : 20ms
Output of voltage excesses : 20ms
Impulse output (power impulse) : max. 20Hz
Line length : up to 30m - not shielded
: larger than 30m - shielded
Inputs and outputs
Connection capacity of terminal points
Rigid/flexible : 0.14 - 1.5mm
2, AWG 28-16
Flexible with ferrules without plastic sleeve : 0.25 - 1.5mm
2
Flexible with ferrules with plastic sleeve : 0.25 - 0.5mm
2
Tightening torque : 0.22 - 0.25Nm
Insulation length : 7mm
